LedsC4 Eko GU10 outdoor downlight urban grey IP66 15-E065-Z5-37

The LedsC4 Eko 15-E065-Z5-37 is an outdoor recessed ceiling downlight with an urban grey finish, aluminum body, and clear polycarbonate diffuser. Its IP66 protection and IK07 resistance are specified by the manufacturer.

Which bulb you need

It uses a GU10 bulb of up to 8 W, not included. The 8 W is the maximum permitted power: the consumption, light tone, and luminous flux depend on the chosen bulb. Dimming also depends on the bulb and the control system.

Before choosing the bulb, check its dimensions and suitability for use in enclosed luminaires. The GU10 base alone does not guarantee that any model will physically fit.

Measurements for installation preparation

• Recessed cut-out: Ø 65 mm.
• External dimensions of the luminaire: Ø 75 × 110 mm high.
• Supported ceiling thickness: 5 to 50 mm.
• Cable included: 1 m.

Before cutting, verify the available space and the manufacturer's mounting requirements. The external height of the luminaire does not replace any installation clearances that the assembly might require.

Technical data sheet

• Brand and collection: LedsC4 Eko.
• Reference: 15-E065-Z5-37.
• EAN: 8445386705668.
• Installation: outdoor recessed ceiling.
• Socket: GU10. Bulb not included.
• Maximum bulb power: 8 W.
• Luminaire power supply: 100–240 V, 50–60 Hz; also verify the voltage supported by the bulb.
• Electrical class: I.
• Protection: IP66. Impact resistance: IK07.
• Structure: aluminum, urban grey finish.
• Diffuser: clear polycarbonate.
• UV protection.
• Net weight: 0.35 kg.
